Machining of transparent materials
Cutting, welding, drilling and engraving of transparent materials with minimization of mechanical stress. Short or ultra-short pulse lasers allow transparent materials to be machined with or without removal of material and to modify their intra-volume physical properties.
The characteristics of the machining of transparent materials process:
Benefits
- Intra-volume machining: localized laser modification – long lasting effect - no need for additional organic layer
- Ablation-free cutting: dust-free - very fast - no taper
- Conventional cutting: fast - with controlled geometry
Performance
- Intra-volume machining: up to 15 MPa of mechanical strength for some glasses, micrometric precision
- Conventional and ablation-free cutting: precision of a few μm
- Conventional cutting: aspect ratio up to 50
Throughput
- Ablation-free cutting: > 100 mm.s-1, can cut up to a thickness of 1 mm in a single pass
- Intra-volume machining: <100 mm.s-1 for welding and a few hundred mm.s-1 for index modification
- Conventional cutting: up to a few tens of mm.s-1 of machining speed depending on the thickness
Laser workstation
- Intra-volume machining: large numerical aperture objective, scanning systems
- Ablation-free cutting: special beam shaping such as Bessel beam
- Conventional cutting: bottom-up approach through material volume
Surface condition
- Ablation-free cutting: surface roughness less than 500 nm
- Conventional cutting: surface roughness less than 1 μm
Materials used for the machining of transparents materials:
- Glass
- Crystals
- Transparents ceramics
Process sheet
Areas of application
- Watchmaking
- Optics
- Display
- Electronics
